Robust Tablet for Data Collection
A very versatile rugged data collection tablet for ultra competitive price
SXTab RTK is a high-performance rugged tablet designed to collect data in the field
This tablet can receive RTK corrections, which lets you have great accuracy. This works with either the Antenna that comes with the tablet or an external antenna. This tablet with your favorite data collection software lets you finally have an all-in-one solution. Equipped with Android 7,0 this tablet is compatible with hundreds of applications.
The SXTab RTK can be used as an all-in-one unit with an internal antenna
It is easy to carry around with the fixed hand strap behind the unit. If you prefer the pole option it is also a possibility. You can use a pole with a clamp adaptor to carry your sub-centimeter wherever you wish. This option also lets you have an external antenna on top of the pole if you are working in areas with a lot of interference.
- 8-inch touch screen
- Certified IP 65 capable of enduring the harshest conditions
- Bluetooth, Wi-Fi, GPS + 2G, 3G, 4G FDD LTE compatible
- Can receive RTK corrections
GET A QUICK QUOTE
INCLUDED ACCESSORIES
INCLUDED ACCESSORIES
| GNSS Module Performance | |
| Channels | Quad-Core ARM Cortex- A53 1.3HZ |
|
Satellite Signal
|
GPS: L1, L2 |
| GLONASS: G1, G2 | |
| BDS:B1,B2 | |
| GALILEO: E1, E5 | |
| Output Rate | <=5HZ |
| Accuracy | Horizontal 1.5m |
| SBAS | 1.25m |
| RTK | 2cm+1ppm |
| System | |
| CPU | Quad-Core ARM Cortex- A53 1.3HZ |
| System | Android 7.0 |
| Memory | 3GB |
| Flash | 16GB |
| LCD Display | |
| Screen-front | 8 TFT LCD |
| Resolution | 1280X800 |
| Brightness | 400 nits |
| Touch screen | 5 points capacitive touch (PCT) |
| Peripherals | |
| Camera | Front 5M, back 13M with a flashlight |
| Sensor | Electronic Compass |
| Acceleration sensor | |
| Gyroscope | |
| Brightness sensor | |
| Barometer | |
| NFC | |
| Barcode scanner | Optional |
| Audio and Vibrator | Microphone speaker vibrator |
| WIFI | |
| Wi-FI | IEEE 802.11 a/b/g/n |
| Bluetooth | Bluetooth 4.1 (BLE, HS- compliant) |
| 2G GSM/GPRS/EDGE | |
| WWAN | 3G WCDMA |
| LTE all Netcom | |
| GPS | GPS / Glonass |
| I/O Interface | |
| USB | port USB 2.0 High speed / OGT – compatible |
| SD Slot | UP à 64 GB |
| Pogo pin | Extra power pins for the car bracket; 5V/2A |
| SIM card slot | Micro-SIM (3FF) Slot |
| Power | |
| Battery capacity | 3.8V 6200mAh, replaced by a rechargeable battery |
| Adaptor Input | AC 100~240v 50~60HZ |
| Adaptor Output | 9V/2A,5v/2A |
| Mechanical & Environmental | |
| Sand, dust & water | IP65 |
| Drop | 1,2 m protection |
| Operating temperature | -10 °C~55 °C |
| Storage temperature | – 20 °C ~65 °C |
| Operating humidity | 5%~95% RH |
|
Dimensions (mm)
|
220X147X20mm
|
| Weight | 550g |
| Key | |
| Power | One |
| Volume | One, bidirectional adjustment |
Coming soon
Our rugged SXTab tablets series feature communication modules and specification, that deliver exceptional performance at an incredible price.
- Resistant to extreme conditions: IP67 and MIL-STD 810G
- 4G LTE, Wi-Fi and Bluetooth Communication
- Android or Windows 10 Operating System
- Resistant to extreme conditions: IP67 and MIL-STD 810G
- Multiports Interface (USB et mini USB)
- Bluetooth, GPS, Wi-Fi, 4G LTE
- Front and Rear camera
- VGA resolution video capture
- Integrated Ion-Lithium battery
- 8 hour battery life
- Multi-touch IPS Screen, 1280 x 800 Sunlight readable
Efficiency and productivity
Our rugged SXTab tablets feature high IP67 protection and are available with Android or Windows OS, allowing the use of several applications on the market.
Advanced technology
Our rugged tablets are equipped with main and front cameras, as well as an integrated GPS module. The 4G LTE modem provides a broadband internet connection.
Learn more by downloading the PDF Data Sheet from “Downloads’ tab below.
